Draw module

Draw draws on the screen that Display opens: points, lines, shapes, text, images, sprites, tilemaps and scenes. It draws on the frame that Display.update() presents, in view coordinates: (0, 0) is the view's top left corner.

JARU Draw module screenshot for drawing text, lines, rectangles, circles, bitmaps, and sprites

use Display

Display.open(320, 240)
var draw = Display.draw    // the Draw module

draw.color = 0xFF0000
draw.circle(100, 100, 50)

You also have it with use Draw, as Draw.circle(…): it is the same module.

Colors

A color is an integer 0xRRGGBB: red, green and blue, from 00 to FF each. Shapes, lines and text are drawn with the color in draw.color.

Color	Value	Example
Red	`0xFF0000`	`draw.color = 0xFF0000`
Green	`0x00FF00`	`draw.color = 0x00FF00`
Blue	`0x0000FF`	`draw.color = 0x0000FF`
White	`0xFFFFFF`	`draw.color = 0xFFFFFF`
Black	`0x000000`	`draw.color = 0x000000`

You can also build it with rgb(r, g, b) (see Standard library). On a board, the screen does not have all those colors: each one becomes the closest one it can show (Memory and limits).

Platforms

	Windows	ESP32 / ESP32-S3	ESP32-P4	ESP32-S31
`font`	Changes nothing: text always comes out with the same font	Picks one of fonts 0 to 8	The same	The same
`font` errors	Throws the exception	Does not throw: writes the error to the serial monitor	The same	The same
`getPixel`	The color of what was drawn	Approximate: in the double buffer, 256 colors	Approximate: 16 bits	Approximate: 16 bits
`cls`	Clears the view	Clears the view; in direct mode, the screen	Clears the view	Clears the view
`line`, `circle`, `polygon` and `getPixel`	In screen coordinates, not view coordinates	View coordinates	View coordinates	View coordinates
`bytes`	Stretches the image over the whole window	At `x`, `y`	At `x`, `y`	At `x`, `y`

The last two rows are bugs of the Windows VM: see Pitfalls.

Functions

Function	What it does	Returns
`cls([color])`	Clears with a color	`nil`
`setPixel(x, y)`	Draws a point	`nil`
`getPixel(x, y)`	Reads the color of a point	The color
`line(x1, y1, x2, y2)`	Draws a line	`nil`
`rect(x, y, width, height [, fill])`	Draws a rectangle	`nil`
`circle(x, y, radius [, fill])`	Draws a circle	`nil`
`ellipse(x, y, radiusX, radiusY [, fill])`	Draws an ellipse	`nil`
`polygon(vertices [, fill])`	Draws a polygon	`true`
`text(x, y, text [, color])`	Writes a text	`nil`
`font()` / `font(n)`	Reads or changes the text font	The font / `true`
`bitmap(x, y, bitmap [, angle])`	Draws an image, with its transparent color	`nil`
`bitmapOpaque(x, y, bitmap [, angle])`	Draws an image without a transparent color	`nil`
`bitmapBatch(bitmap, positions)`	Draws an image in many places	`nil`
`gridBitmap(grid, value, bitmap, x0, y0, stepX, stepY)`	Draws an image on the cells of a GridMap that have a value	`nil`
`bytes(x, y, width, height, bytes, palette)`	Draws a Bytes block with a palette	`nil`
`sprite(sprite)`	Draws a sprite, or a list or an array of sprites	`nil`
`tilemap(grid [, tileset [, empty]])`	Draws a tilemap	`nil`
`scene(scene)`	Draws a scene: its map and its sprites	`nil`

With an argument of another type, the Draw functions do not throw an exception: they return an error value and draw nothing (see Errors and exceptions). The ones that do throw are tilemap, scene and, on Windows, font.

cls

Clears with a color, or with colorBG if you give it none.

draw.cls()           // clears with colorBG
draw.cls(0x000000)   // clears with black

In double buffer mode it is not needed: Display.update() already starts each frame by clearing the view with colorBG (autoClear). It clears only the view: what is outside, like a loadTFT frame, stays. On the ESP32 and the S3, in direct mode, it clears the whole screen. The color has to be an integer.

setPixel

Draws a point with the color in draw.color.

draw.setPixel(100, 50)    // a point at (100, 50)
draw.setPixel([150, 75])  // also with a list [x, y]

getPixel

Reads the color of a point of the frame you are drawing, as an integer 0xRRGGBB.

draw.color = 0xFF0000
draw.setPixel(100, 50)
println(draw.getPixel(100, 50).toHex())   // FF0000

It reads the frame that is not shown yet: the one the next update() will present. Right after an update(), it reads the new frame, already cleared.
On Windows it gives the color of what was drawn. Images are stored in 16 bits, so the color of an image comes back approximate: a 0x123456 reads as 0x103452.
On a board, the color is approximate: the double buffer of the ESP32 and the S3 has 256 colors, and that of the P4 and the S31, 16 bits per pixel.
On Windows it counts from the corner of the screen, not of the view (Pitfalls).

line

Draws a line between two points with the current color.

draw.line(x1, y1, x2, y2)

Parameter	Description
`x1, y1`	The start point
`x2, y2`	The end point

draw.color = 0xFFFFFF
draw.line(0, 0, 319, 239)    // White diagonal
draw.line(160, 0, 160, 240)  // Vertical line

rect

Draws a rectangle, outlined or filled, with the current color.

draw.rect(x, y, width, height [, fill])

Parameter	Type	Description
`x, y`	number	The top left corner
`width`	number	The width
`height`	number	The height
`fill`	`true` / `false`	`true` for filled, `false` for outline (optional, `false` by default)

draw.color = 0xFFFF00
draw.rect(50, 50, 100, 80)        // Yellow outline
draw.rect(50, 50, 100, 80, true)  // Yellow filled

Coordinates and sizes take decimals, which are truncated, in this function and in the other shapes. fill has to be true or false: with anything else, it draws nothing.

circle

Draws a circle, outlined or filled, with the current color.

draw.circle(x, y, radius [, fill])

Parameter	Type	Description
`x, y`	number	The center
`radius`	number	The radius
`fill`	`true` / `false`	`true` for filled, `false` for outline (optional, `false` by default)

draw.color = 0x00FF00
draw.circle(160, 120, 50)        // Green outline
draw.circle(160, 120, 50, true)  // Green filled

ellipse

Draws an ellipse, outlined or filled, with the current color.

draw.ellipse(x, y, radiusX, radiusY [, fill])

Parameter	Type	Description
`x, y`	number	The center
`radiusX, radiusY`	number	The horizontal and vertical radii
`fill`	`true` / `false`	`true` for filled, `false` for outline (optional, `false` by default)

draw.color = 0xFF00FF
draw.ellipse(160, 120, 80, 40)        // Magenta outline
draw.ellipse(160, 120, 80, 40, true)  // Magenta filled

polygon

Draws a polygon from a list of vertices, outlined or filled.

draw.polygon(vertices [, fill])

Parameter	Type	Description
`vertices`	list	The coordinates, in order: `[x1, y1, x2, y2, x3, y3, ...]`
`fill`	`true` / `false`	`true` for filled, `false` for outline (optional, `false` by default)

draw.color = 0xFFFFFF
// Outlined triangle
var vertices = [160, 50, 100, 150, 220, 150]
draw.polygon(vertices)

// Filled pentagon
draw.color = 0xFF8000
var penta = [160, 40, 200, 80, 185, 140, 135, 140, 120, 80]
draw.polygon(penta, true)

info

The vertices go in a list […], with at least three vertices (six numbers). With an odd number of elements it returns an error value and draws nothing. Filling also works with concave polygons. It is the only shape that returns true.

text

Writes a text on the screen.

draw.text(x, y, text [, color])

Parameter	Description
`x, y`	The top left corner of the text
`text`	A string
`color`	The text color (optional, uses `draw.color` if not specified)

draw.text(10, 10, "Hello World", 0x00FF00)
draw.text(10, 30, "Score: 100")  // with draw.color

var points = 250
draw.text(10, 50, "Points: " + points.toString())

text has to be a string: with a number it writes nothing. Turn it into a string with toString().
On a board, the font is the one in draw.font. On Windows, text always comes out with the same font (font/consola.ttf, at size 13), whichever you pick.
It is the most expensive thing in Draw. On Windows, each call draws the text with the TrueType font from scratch: measured in a game on Windows, five short texts took 3.4 ms of a 4.8 ms frame. What changes every frame (points, lives, a clock), draw it with images: a sprite with one frame per digit, or draw.bitmap. Keep draw.text for screens that do not move, such as the title.
With an empty string ("") it draws nothing.

font

Reads or changes the text font.

// The current font (1, the default)
var f = draw.font()

// Another font
draw.font(2)

Font	Description	Height	Characters
`0`	Small font (6x8 bitmap)	8 px	Full ASCII
`1`	Default font (alias of `0`)	8 px	Full ASCII
`2`	Medium font	16 px	96 ASCII characters
`4`	Large font	26 px	96 ASCII characters
`6`	Clock font	48 px	`0-9` `:` `-` `.` `a` `p` `m`
`7`	7-segment font	48 px	`0-9` `:` `-` `.`
`8`	Huge font	75 px	`0-9` `:` `-` `.`

Valid range

The range is 0 to 8. Indices 3 and 5 exist for compatibility and are aliases of font 0. With another value, or with something that is not an integer, the font does not change: on Windows it throws ERR_INVALID_VALUE or ERR_TYPE_MISMATCH, and on a board it writes the error to the serial monitor and returns an error value.

Fonts 6, 7 and 8

They do not contain the alphabet: they are meant for clocks and scoreboards. Any character not in the list is drawn as a space, it does not raise an error. In font 6, the vertical bar | is a narrow space, useful to align the time.

The fonts belong to the boards. On Windows, draw.font changes what draw.font() returns, but text comes out the same with any of them.

bitmap

Draws a Bitmap image, with optional rotation. The image's transparent color is not drawn.

draw.bitmap(x, y, bitmap [, angle])

Parameter	Description
`x, y`	The top left corner
`bitmap`	The image, from `Bitmap.load`
`angle`	Degrees of rotation, around the center of the image (optional, 0 by default; decimals are truncated)

use Display, Bitmap

Display.open(320, 240)
var draw = Display.draw
var img = Bitmap.load("Images/image.bmp")
draw.bitmap(100, 50, img)      // Not rotated
draw.bitmap(100, 50, img, 45)  // Rotated 45 degrees

The transparent color is the image's: black, unless you gave it another one when loading it with Bitmap.load or with tcolor.

bitmapOpaque

Draws an image like draw.bitmap, but with all its pixels: also those of the transparent color.

draw.bitmapOpaque(x, y, bitmap [, angle])

use Display, Bitmap

Display.open(320, 240)
var draw = Display.draw
var background = Bitmap.load("Images/background.bmp")
draw.bitmapOpaque(0, 0, background)   // black is drawn too

It is meant for a background, or for an image with pure black that has to show, without changing its transparent color. The parameters are those of draw.bitmap. On Windows it costs more than draw.bitmap: it prepares the image on every call.

bitmapBatch

Draws the same image in many places with a single call. It is faster than calling draw.bitmap in a loop.

draw.bitmapBatch(bitmap, positions)

Parameter	Description
`bitmap`	The image
`positions`	An array (`{…}`) with the corners: `{x0, y0, x1, y1, ...}`. With a list (`[…]`), or with an odd number of elements, it returns an error value and draws nothing

use Display, Bitmap

Display.open(320, 240)
var draw = Display.draw
var coin = Bitmap.load("Images/coin.bmp")
var pos = {10, 20, 50, 20, 90, 20, 130, 20}

draw.bitmapBatch(coin, pos)  // four coins at once

It does not rotate the images. An element that is not a number is skipped.
The transparent color is the image's (the one from Bitmap.load or tcolor), as in draw.bitmap.

Performance

bitmapBatch is especially useful on ESP32: it reads the image's pixels only once for all the positions, and it skips those that fall outside the view.

gridBitmap

Draws an image on every cell of a GridMap that has a value. It is meant for drawing the loose things of a map, such as coins.

draw.gridBitmap(grid, value, bitmap, x0, y0, stepX, stepY)

Parameter	Description
`grid`	The GridMap
`value`	An integer from 0 to 255: the value the cell must have
`bitmap`	The image drawn on those cells
`x0, y0`	Where cell `(0, 0)` goes, in the view
`stepX, stepY`	The distance in pixels from one cell to the next

use Display, GridMap, Bitmap

Display.open(320, 240)
var draw = Display.draw
var map = GridMap.new(10, 10)
map.set(3, 2, 1)
var wall = Bitmap.load("Images/wall.bmp")

// The "wall" image on every cell with value 1
draw.gridBitmap(map, 1, wall, 0, 0, 16, 16)

It does not use the map's position (x, y): it uses x0 and y0. It goes through the whole map on every call. The transparent color is the image's, on a board too.

bytes

Draws a Bytes block as an image: each byte is a color of the palette.

draw.bytes(x, y, width, height, bytesObject, palette)

Parameter	Description
`x, y`	The top left corner
`width, height`	The size of the image in pixels
`bytesObject`	A Bytes object with one byte per pixel, row by row: the number of the color in the palette
`palette`	An array (`{…}`) of up to 256 colors `0xRRGGBB`

use Display, Bytes

Display.open(320, 240)
var draw = Display.draw
var palette = {0x000000, 0xFF0000, 0x00FF00, 0x0000FF}
var data = Bytes.new(16)   // 4 x 4 pixels
data.fill(1)               // all of color 1, red
draw.bytes(100, 100, 4, 4, data, palette)

x, y, width and height have to be integers.
Each byte has to be a color of the palette: a larger byte draws some random color.
It has no transparent color: it draws every pixel.
If the palette isn't an array, like a list […], it returns the error value ERR_TYPE_MISMATCH, and if the Bytes object has fewer than width × height bytes, ERR_INDEX_OUT_OF_RANGE. In both cases it draws nothing.

On Windows, the image fills the whole window

On Windows, draw.bytes does not use x or y: it stretches the image over the whole window. On a board it is drawn in its place and at its size.

sprite

Draws a sprite, or all the sprites of a list or an array.

draw.sprite(sprite)
draw.sprite(spriteList)
draw.sprite(spriteArray)

Parameter	Description
`sprite`	A sprite
`spriteList`	A list or an array of sprites

use Display, Bitmap, Sprite

Display.open(320, 240)
var draw = Display.draw
var s = Sprite.new(Bitmap.load("Images/frame1.bmp"))
s.addImage(Bitmap.load("Images/frame2.bmp"))
s.x = 100
s.y = 100

draw.sprite(s)

The sprite goes with its pivot at x, y, rotated (angle) and flipped (flipX, flipY).
It only draws the sprites with active = true and at least one frame. In a list, it skips what is not a sprite.

Animations

Each time it draws a sprite, draw.sprite advances its animation according to frameRate, loop and yoyo, and its automatic rotation, spin. A sprite that is not drawn is not animated. Draw each sprite only once per frame: the spin rotation is applied on every call.

tilemap

Draws a GridMap as a tilemap: each cell is the number of a tile in the tileset.

draw.tilemap(grid [, tileset [, empty]])

Parameter	Description
`grid`	The GridMap, with the tile size set (`grid.tSize(width, height)`)
`tileset`	The image with the tiles (optional if the map has one in `grid.tileset`)
`empty`	The tile that is not drawn (optional; by default, the one in `grid.tEmpty()`, 255)

use Display, GridMap, Bitmap

Display.open(320, 240)
var draw = Display.draw
var map = GridMap.new(20, 15)
map.tSize(16, 16)
map.tileset = Bitmap.load("Images/tiles.bmp")

draw.tilemap(map)                   // with the map's tileset
draw.tilemap(map, map.tileset, 0)   // tile 0 is not drawn either

The tiles are counted in the tileset from left to right and from top to bottom, starting at 0, with the size in tSize. The value of each cell is the tile drawn on it. Cells with 255 are never drawn.
The position of the map is grid.x and grid.y: where cell (0, 0) goes in the view. To scroll, change them (with negative values the map moves left and up). Only the tiles that fall in the view are drawn.
With wrapX or wrapY, the map repeats on that axis.
It throws an exception if the tileset or the tile size is missing or the tileset is smaller than a tile (ERR_INVALID_VALUE), or if an argument is of another type (ERR_TYPE_MISMATCH).
The transparent color is the tileset's (the one from Bitmap.load or tcolor).
On Windows, the whole map is kept already drawn, and it is drawn again when a cell changes with set.

Scrolling

With a Scene, draw.scene draws the scene's map with the camera applied: there is no need to move grid.x and grid.y by hand.

scene

Draws a whole scene: first its GridMap (if it has one, with setGridMap) and then its sprites, with the camera applied.

draw.scene(scene)

Parameter	Description
`scene`	A Scene object, from `Scene.new()`

use Display, Scene

Display.open(320, 240)
Display.fps = 30
var draw = Display.draw
var level = Scene.new()
// ... the scene's sprites, map and camera

level.update()
draw.scene(level)
Display.update()

The scene's map has to have its tileset in grid.tileset: otherwise, it throws ERR_INVALID_VALUE.
It draws the active sprites the camera sees (with a 16 pixel margin), in the order of the scene's list. Those outside are not drawn, and their animation does not advance.
With something that is not a scene, it throws ERR_TYPE_MISMATCH.

tip

The scene camera (the one you place with scene.setCamera(x, y) or that follows a sprite with scene.follow(sprite), and that you read with scene.getCamera()) is applied automatically to both the GridMap and all sprites. Only sprites marked as active and visible within the camera area are drawn.

Properties

Property	Type	Default	Read / write
`color`	integer `0xRRGGBB`	`0xFFFFFF` (white)	Both
`colorBG`	integer `0xRRGGBB`	`0x000000` (black)	Both

Both have to be integers: a value of another type does not change them.

color

The color used to draw points, lines, shapes and text.

// Set color
draw.color = 0xFF0000

// Get current color
var c = draw.color

colorBG

The background color: the one cls() uses without arguments, and the one Display.update() uses to clear each frame (with autoClear).

// Set background color
draw.colorBG = 0x000080

// Get current background color
var bg = draw.colorBG

Complete example

A ball bounces for ten seconds in front of a floor and a star. Each frame starts cleared with colorBG.

use Display

Display.open(320, 240)
Display.fps = 30
var draw = Display.draw
draw.colorBG = 0x000020            // update() clears with this color

var ballX = 160.0
var ballY = 60.0
var vx = 90.0                      // pixels per second
var vy = 60.0
var star = [160, 20, 168, 42, 192, 42, 173, 56, 180, 80, 160, 66, 140, 80, 147, 56, 128, 42, 152, 42]

for (var i = 0; i < 300; i++)      // 10 seconds
    draw.color = 0x228B22
    draw.rect(0, 200, 320, 40, true)          // the floor
    draw.color = 0xFFD700
    draw.polygon(star, true)
    draw.color = 0xFF4040
    draw.circle(ballX, ballY, 12, true)       // the ball, filled
    draw.color = 0xFFFFFF
    draw.circle(ballX, ballY, 12)             // and its outline
    draw.line(0, 199, 319, 199)
    draw.text(8, 8, "Draw", 0xFFFFFF)
    Display.update()

    ballX = ballX + vx * Display.dt
    ballY = ballY + vy * Display.dt
    if (ballX < 12 or ballX > 308) then vx = 0 - vx end
    if (ballY < 12 or ballY > 188) then vy = 0 - vy end
end
Display.close()

Pitfalls and known issues

On Windows, line, circle, polygon and getPixel do not count from the view. They use screen coordinates. With a view smaller than the screen (Display.viewWidth), they come out shifted compared with rect, ellipse, text and images. Without a view, or with the view the size of the screen, it does not show.
On Windows, draw.bytes stretches the image over the whole window (see bytes).
On Windows, draw.tilemap does not see what grid.clear() changes. It keeps drawing the old map until the next grid.set(). After a clear, do a set of any cell.
The order of the sprites in draw.scene changes when one is removed. When a sprite leaves the scene, the last one of the list takes its slot: from then on it is drawn before others it used to cover. Layers, in the scene editor, explains it.

All the known issues of JARU, together, are in Known issues.

Colors​

Platforms​

Functions​

cls​

setPixel​

getPixel​

line​

rect​

circle​

ellipse​

polygon​

text​

font​

bitmap​

bitmapOpaque​

bitmapBatch​

gridBitmap​

bytes​

sprite​

tilemap​

scene​

Properties​

color​

colorBG​

Complete example​

Pitfalls and known issues​
